Automatic 5 Gallon Water Filling Machine – Efficient Bottling Solution for Businesses
The Automatic 5 Gallon Water Filling Machine is an advanced, efficient solution designed to streamline the water bottling process. Ideal for high-volume production, this machine automatically fills 5-gallon water bottles with precision and speed, ensuring consistent quality and minimizing human labor. With features like automatic capping, leak-proof design, and customizable settings, the machine is perfect for businesses looking to scale their water bottling operations.
Specifications
| TYPE | QGF-100 | QGF-240 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 |
| filling heads | 1 | 2 | 3 | 4 | 8 | 8 | 8 |
| barre size(mm) | Φ276×490 | ||||||
| Capacity(b/h) | 60-100 | 100-240 | 250-300 | 400 | 800 | 800 | 800 |
| gas pressure(MPa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 |
| gas consumption(m3/min) | 0.37 | 0.37 | 0.6 | 0.8 | 1 | 1.5 | 1.8 |
| Motor power kw | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9.75 | 13.5 |
| Rated voltage | 380V/50HZ | ||||||
| Weight (kg) | 680 | 800 | 1500 | 2100 | 3000 | 3500 | 4500 |
Video
Description
One of the standout features of the Automatic 5 Gallon Water Filling Machine is its versatility in adapting to different production requirements. Beyond just filling, many models also offer automatic capping and sealing, ensuring each bottle is securely closed before moving on to the next stage of production. Some machines come equipped with additional functionalities such as labeling, which allows for a fully automated bottling process from start to finish. This integration of multiple functions in a single system not only saves time but also streamlines maintenance and operational management. With durable, corrosion-resistant components, these machines are built to withstand the rigorous demands of high-output environments, providing long-term reliability and a high return on investment.
